Roof Purlins
Overview
ARC Metalcentre sources a variety of steel roof purlins, both C and Z, manufactured in Australia and available in a range of sizes.
Strong, practical steel sections ready to go for your next project.
Specifications
| Designation | Size mm x mm x mm | Mass kg/m |
|---|---|---|
| C 10010 | 102 x 51 x 1.0 | 1.78 |
| C 10012 | 102 x 51 x 1.2 | 2.10 |
| C 10015 | 102 x 51 x 1.5 | 2.62 |
| C 10019 | 102 x 51 x 1.9 | 3.29 |
| C 15024 | 152 x 64 x 1.2 | 2.89 |
| C 15015 | 152 x 64 x 1.5 | 3.59 |
| C 15019 | 152 x 64 x 1.9 | 4.51 |
| C 15024 | 152 x 76 x 2.4 | 5.70 |
| C 20015 | 203 x 76 x 1.5 | 4.49 |
| C 20019 | 203 x 76 x 1.9 | 5.74 |
| C 20024 | 203 x 76 x 2.4 | 7.24 |
| C 25019 | 254 x 76 x 1.9 | 6.50 |
| C 25024 | 254 x 76 x 2.4 | 8.16 |
| C 30024 | 300 x 96 x 2.4 | 10.1 |
| C 30030 | 300 x 96 x 3.0 | 12.6 |
| C 35030 | 350 x 125 x 3.0 | 15.1 |
| Size | Web D (mm) | Thickness (mm) | Flange E (mm) | Flange F (mm) | Flange L (mm) | Mass kg/m |
|---|---|---|---|---|---|---|
| Z 10010 | 102.0 | 1.0 | 53.0 | 49.0 | 12.5 | 1.78 |
| Z 10012 | 102.0 | 1.2 | 53.0 | 49.0 | 12.5 | 2.10 |
| Z 10015 | 102.0 | 1.5 | 53.0 | 49.0 | 13.5 | 2.62 |
| Z 10019 | 102.0 | 1.9 | 53.0 | 49.0 | 14.5 | 3.29 |
| Z 15012 | 152.0 | 1.2 | 66 | 61 | 15.5 | 2.89 |
| Z 15015 | 152.0 | 1.5 | 66 | 61 | 16.5 | 3.59 |
| Z 15019 | 152.0 | 1.9 | 66 | 61 | 17.5 | 4.51 |
| Z 15024 | 152.0 | 2.4 | 70 | 60 | 19.5 | 5.70 |
| Z 20015 | 203.0 | 1.5 | 77 | 74 | 15.0 | 4.49 |
| Z 20019 | 203.0 | 1.9 | 80 | 74 | 18.5 | 5.74 |
| Z 20024 | 203.0 | 2.4 | 82 | 73 | 21.5 | 7.24 |
| Z 25019 | 254 | 2.4 | 79 | 74 | 18.0 | 6.50 |
| Z 25024 | 254 | 2.4 | 79 | 73 | 21.0 | 8.16 |
| Z 30024 | 300 | 2.4 | 105 | 93 | 27.0 | 10.1 |
| Z 30030 | 300 | 3.0 | 107 | 93 | 31.0 | 12.6 |
| Z 35030 | 350 | 3.0 | 134 | 121 | 30.0 | 15.1 |
